Aluminum Bar Cutting Furnace (for long bar)
Aluminum bar cutting furnace has two kinds of models, one is for a single bar, and another kind is for two or more bars, it can avoid wasting raw materials.
Photos of
Detailed introduction
Description
Aluminum bar cutting furnace has two kinds of models, one is for a single bar, and another kind is for two or more bars. Compared to old equipment, this kind of cutting furnace can avoid wasting raw materials.
Main Technical Parameters
| Aluminum Bar Cutting Furnace (for long bar) | |
| Aluminum Rod Length: | 6500m (can be adjusted according to customer requirements) |
| Aluminum Rod Diameter: | ψ80--φ305 (can be selected according to customer requirements) |
| Working Temperature: | 460--520℃ |
| Total Power: | 22KW 44KW (changes according to the diameter of the aluminum rod) |
| Shearing Force: | 40T-120T (changes according to the diameter of the aluminum rod) |
Difference between Single Long Rod Hot Shear Furnace And Multiple Long Rod Hot Shearing Furnace
1. Structure
In a single-rod furnace, only one rod after another can enter the furnace and then be heated. The multi-rod furnace can send multiple rods into the furnace for heating at one time.
2. Heating
Single-rod furnaces are heated by spraying fire directly onto the rods, while multi-rod furnaces are heated with hot gas.
3. Advantages and Disadvantages of These Two Types of Equipment
Single Long Rod Hot Shear Furnace | Multiple Long Rod Hot Shearing Furnace | |
| Advantages | 1. Low energy consumption. 2. It is convenient to control the temperature of the aluminum rod. 3. The length of the aluminum rod can be unlimited. 4. The speed of the rod is easy to control. | 1. The aluminum rod takes a long time to preheat in the furnace. 2. The temperature of the aluminum rod is more uniform. 3. The furnace body has good thermal insulation performance and a high utilization rate of heat energy. 4. Multiple rods can be heated at the same time, with high working efficiency |
| Disadvantages | 1. Low work efficiency. 2. The heat loss is very large. 3. The aluminum rod is not uniform and is easily affected by the outside world. | 1. High energy consumption. 2. The length of the aluminum rod is limited. 3. The furnace has a large volume and poor flexibility. |
Range of Work
It is used for the rapid heating of aluminum rods and automatic cutting of aluminum rods, providing conditions for advanced extrusion processes such as isothermal extrusion.
